Главная / Каталог / Щеточная машина Bobcat для погрузчиков / ЩЕТОЧНАЯ МАШИНА (54-- 4395) (60-- 4347) (72-- 4354)

ЩЕТОЧНАЯ МАШИНА (54-- 4395) (60-- 4347) (72-- 4354) — Продажа в Казахстане Цены от официального дилера с доставкой в Алматы, Астану и регионы

Name: ЩЕТОЧНАЯ МАШИНА (54-- 4395) (60-- 4347) (72-- 4354)
Brand: Bobcat
SKU: setocnaa-masina-54-4395-60-4347-72-4354-72298
Availability: InStock

Спецтехника ЩЕТОЧНАЯ МАШИНА (54-- 4395) (60-- 4347) (72-- 4354) - главное фото

Купить ЩЕТОЧНАЯ МАШИНА (54-- 4395) (60-- 4347) (72-- 4354) в Казахстане

Техника доступна в:

Рассрочка Лизинг Trade-In

Полный спектр услуг:

Сервис Офисы продаж Гарантия

Для Вашего удобства:

Запчасти Доставка

Характеристики и описание

Габариты, схема

Техническая документация

1	Артикул: 6569233, SAFETY TREAD
2	Артикул: 84G3712, BOLT 5
3	Артикул: 6594797, COVER 54-- (1371,6mm)
4	Артикул: 6594382, COVER 60-- (1524mm)
5	Артикул: 6594388, COVER 72-- (1828,8mm)
6	Артикул: 6594792, HINGE PIN 54-- (1371,6mm)
7	Артикул: 6591249, HINGE PIN 60-- (1524mm)
8	Артикул: 6594364, HINGE PIN 72-- (1828,8mm)
9	Артикул: 6813246, SPROCKET, SWEEPER Was 6594342 - A
10	Артикул: 15G505, SCREW
11	Артикул: 6634899, KEY woodruff
12	Артикул: 6594348, GUARD
13	Артикул: 6594483, HINGE guard
14	Артикул: 27E8, WASHER 10
15	Артикул: 17C828, BOLT
16	Артикул: 6594642, CHAIN
17	Артикул: 6515191, LINK connector, press fit
18	Артикул: 6632387, LINK connector, W/Clip
19	Артикул: 6594789, FRAME 54-- (1371,6mm)
20	Артикул: FRAME, FRAME See BTI300 NLA - 60-- (1524mm) For weld on cutting edge - Order 6705476 - Was 6591243 - A
21	Артикул: 6705476, FRAME 60-- (1524mm)
22	Артикул: FRAME, FRAME See BTI300 NLA - 72-- (1828,8mm) For weld on cutting edge - Order 6705478 - Was 6594358 - A
23	Артикул: 6705478, FRAME 72-- (1828,8mm)
24	Артикул: 6537694, HOSE Was 6594372 - A
25	Артикул: 15K7, FITTING W/Ref. 14
26	Артикул: 79K10, O RING 10
27	Артикул: 6594341, MOUNT
28	Артикул: MOTOR, MOTOR See Illustration SWEEPER/ B18046A See Illustration SWEEPER/ D1757A See Illustration SWEEPER/ B18046
29	Артикул: 85D6, NUT, 5 Was 85D000008B - B
30	Артикул: 6531055, DECAL warning - Was 6594379 - A
31	Артикул: 6809831, DECAL, LOGO BOBCAT AND HEAD Was 6727307 - B
32	Артикул: DECAL, DECAL NLA - Bobcat Sweeper - Order 6727323 - Was 6594380 - A
33	Артикул: DECAL, DECAL NLA - 54-- Bobcat Sweeper - Order 6727323 - Was 6531053 - A
34	Артикул: 6727323, DECAL, LOGO BOBCAT AND HEAD
35	Артикул: DECAL, DECAL NLA - Bobcat Sweeper - Order 6727324 - Was 6594377 - A
36	Артикул: DECAL, DECAL NLA - 54-- Bobcat Sweeper - Order 6727324 - Was 6531052 - A
37	Артикул: 6727324, DECAL, LOGO BOBCAT AND HEAD
38	Артикул: 6708822, DECAL, WARNING See Illustration SWEEPER/ NA6248 - Was 6577324 - A
39	Артикул: 7130144, DECAL, WARNING See Illustration SWEEPER/ NA6248 - no-text
40	Артикул: 61D16, LCKNUT
41	Артикул: 6594345, BOLT
42	Артикул: 6594397, EDGE, CUTTING WELD ON 55.09-- 54-- (1371,6mm)
43	Артикул: 6577904, CUTTING EDGE 60-- (1524mm) - Was 6594393 - A
44	Артикул: 6594356, EDGE, CUTTING WELD ON BEVELED 73-- 72-- (1828,8mm)
45	Артикул: BUCKET, BUCKET NLA - 54-- (1371,6mm) - Order Ref. 36 - Was 6594396 - A
46	Артикул: BUCKET, BUCKET NLA - 60-- (1524mm) - Order Ref. 36 - Was 6705477 - A
47	Артикул: BUCKET, BUCKET NLA - 72-- (1828,8mm) - Order Ref. 36 - Was 6705479 - A
48	Артикул: 45K7, CONNECTR
49	Артикул: 86F7, LOCK NUT
50	Артикул: 17C680, BOLT
51	Артикул: 6563353, CLAMP
52	Артикул: 6647668, KNOB plastic
53	Артикул: 6594371, HOSE
54	Артикул: 6598758, COUPLER, POPPET FEMALE straight
55	Артикул: 7246790, COUPLER, FF FEMALE See BTI433att - straight - Was 6672960 - A
56	Артикул: 6598757, COUPLER, POPPET MALE straight
57	Артикул: 7246777, COUPLER, FF MALE See BTI433att - Was 6674688 - A
58	Артикул: SEAL, SEAL See BTI433att - blue - front - 7251807 or 6679841
59	Артикул: 35C820, BOLT Was 6511995 - A
60	Артикул: BUCKET, BUCKET See BTI300 NLA - 54-- - W/Ref. 42 - Was 6704042 - A
61	Артикул: BUCKET, BUCKET See BTI300 NLA - 60-- (1524 mm) - W/Ref. 42 - Was 6705477 - A
62	Артикул: BUCKET, BUCKET See BTI300 NLA - 72-- (1829 mm) - W/Ref. 42 - Was 6705479 - A
63	Артикул: 17K7, ELBOW Use with poppet couplers
64	Артикул: 17KB1012, FITTING, HYD ELBOW Use with flush face couplers - Was 1302104B - A
65	Артикул: CUTTING, CUTTING EDGE NLA - 18-- (457,2 mm) - Use (3) with 54-- (1371,6 mm) bucket - Use (2) with 60-- (1524 mm) bucket & (1) of Ref. 39 - Order Ref. 47 - Was 6704029 - A
66	Артикул: CUTTING, CUTTING EDGE NLA - 24-- (609,6 mm) - Use (1) with 60-- (1524 mm) bucket & (2) of Ref. 38 - Use (3) with 72-- (1828,8 mm) bucket - Order Ref. 47 - Was 6704009 - A
67	Артикул: 6704903, BOLT 5 1/2-- - Use Qty. 9 with 54-- (1372mm) bucket, Qty. 10 with 60-- (1524mm) bucket & Qty. 12 with 72-- (1829mm) bucket
68	Артикул: 39C1032, BOLT 5/8-- - Use Qty. 9 with 54-- (1372mm) bucket, Qty. 10 with 60-- (1524mm) bucket & Qty. 12 with 72-- (1829mm) bucket
69	Артикул: 85D8, NUT, 5 1/2-- - Use Qty. 9 with 54-- (1372mm) bucket, Qty. 10 with 60-- (1524mm) bucket & Qty. 12 with 72-- (1829mm) bucket
70	Артикул: 93D10, NUT 5/8-- - Use Qty. 9 with 54-- (1372mm) bucket, Qty. 10 with 60-- (1524mm) bucket & Qty. 12 with 72-- (1829mm) bucket - Was 85D000010B - B
71	Артикул: 6707831, BAR 54-- (1372mm) - Was 6704039 - A
72	Артикул: 6707150, BAR 60--(1524mm) - Was 6704030 - A
73	Артикул: 6707843, BAR 72--(1829mm) - Was 6704008 - A
74	Артикул: 872229, WASHER
75	Артикул: 6706160, GUIDE
76	Артикул: 37C660, BOLT
77	Артикул: 6704007, BRACKET
78	Артикул: 6805366, EDGE, CUTTING BOLT ON BEVELED REV 53.88-- Uses 39C1032 bolt & 93D10B nut - SEE NOTE - Was 6706554 - A
79	Артикул: 6805367, EDGE, CUTTING BOLT-ON 60-- Uses 39C1032 bolt & 93D10B nut - SEE NOTE - Was 6706554 - A
80	Артикул: 6805368, EDGE, CUTTING BOLT-ON 72-- Uses 39C1032 bolt & 93D10B nut - SEE NOTE - Was 6706554 - A
81	Артикул: 85D8, NUT, 5
